High-Temp Coatings
Energy Saving
Solutions that reduce power consumption and improve operational efficiency, resulting into Power and Cost Savings
Corrosion Guard
Advanced coatings that prevent rust and extend equipment lifespan thus providing maximum protection against Corrosion & Erosion
Features:
- Anti-oxidation/ Anti-Erosion
- Service Temperature: 27500 C+10%
- High Temperature Electrical insulating
- High temperature resistant
- Non-sticky against molten metal
- Excellent adhesion to surface
- No affect of acid fumes, So2, So3
- Protection from thermal shocks
Industry Applications:
- Electric Arc Furnace
- Reheating Furnace
- Induction Furnace
- Burner Equipment
- Black Refractory
- Graphitization of Electrodes
- Sintering Furnaces
- Industrial Burners
Thermoplast-TI acts as a thermal barrier with minimum expansion (and thermal conductivity co‐efficient) when exposed to temperatures around/above 700 Degree C. Formulated with AEPCO’s proprietary binder (ALS‐21), natural minerals and focus on developing a homogenous mass having enough adhesive strength (to bind perfectly to the metal surface), to attain optimum compressive strength / mechanical load bearing capacity (of molten metal and refractory bricks) besides minimum shrinkage after complete drying.
Temperature Range: 1200ºC + 10%
Industry Applications:
- Rotary Kiln
- Outer shells of electric arc, reheating, submerged furnaces
- Foundry Ladles and Tundish
- Low Nox Burners
- Boilers
Features:
- High temperature resistant
- Highly electrically insulating at elevated temperatures
- Doesn’t absorb moisture after complete cure.
- Neutral in nature against acidic/alkaline atmosphere
- Anti-‐oxidant and anti-‐corrosive
- Highly thermal conducting and bonding increases with rise in temperature
- Prevents sparking and doesn’t carbonize
- High dielectric strength and thermal shock resistance
- Longer service life and prevents power loss
- Maintains leakage current at minimum through-‐out coil’s service life
- Applied on induction furnace coil, bus bars, FRP retainers, Spacers, Yokes
Technical Data
- Density: At 2500C, 1.2 Kg/Liter
- Color: Brown
- Solid contents: 58% + 2%
- Service temperature: 3000C + 10%
- Electrical properties: Fully cured 1mm thick coating at 1400C for 8-‐9 hours:
- Di-electric strength at 2000C: 60 KV
- 24 hours water immersion at 300C: 60 KV
- 24 hours acid vapors at 1000C: >60 KV
Gallery
Snapshots showcasing aepco’s advanced coatings and industrial solutions.
